Drawings
Specs
| Model No. | Boundary Dim (mm) | Mounting holes | Basic load rating (kN) | Mass | ||||||||||||
| Da | di | Ha | hi | Di | da | La(mm) | nB 1) | dB(mm) | ds(mm) | ts(mm) | Ca | Coa | Cr | Cor | kg | |
| XV30 | 75 | 30 | 14 | 15 | 42.5 | 41.5 | 60 | 12 | 4.6 | 8 | 4.6 | 11.6 | 26 | 7.4 | 10.4 | 0.37 |
